ROI Universal Clamp of Solar Panel Mounts for Roof Types:
With proper installation torque, it will not crush or puncture roof metal sheet. Over‑tightening bolts may cause roof‑sheet deformation.
Metal rooftop PV systems, commercial factory roof PV, solar carport roof projects. Not for tile‑roof or concrete‑flat‑roof without metal ribs.
Custom‑made clamp opening size for special roof profiles is available subject to certain order quantity. Standard models are in‑stock for fast delivery.
Payment :
T/TProduct Origin :
ChinaLead Time :
7-10 days
It eliminates the need for customizing different clamps for specific panel or rail models, significantly reducing inventory costs for installers and project managers.
Wide Compatibility
Robust Load-Bearing Capacity
Tool-Free Quick Installation (Optional Models)
Dual Application Scenarios
ons.
It has the advantages of low land occupation, high utilization efficiency, and low overall cost. The unique water drainage, with internal drainage and external diversion, allows rainwater to flow separately and be promptly drained away. It can be flexibly designed according to the wind speed and snow load in different regions.
A: Universal clamp is a multi‑purpose fastening component for roof solar mounting systems. It is widely used for metal roof PV projects, directly fixing onto roof rib / standing seam without roof penetration. It connects solar mounting rails to roof substrate, transferring wind and snow loads.
A: Main body: 6005‑T5 / 6063‑T5 anodized aluminum alloy. Matching bolts and washers: SUS304 stainless steel. Good anti‑corrosion performance, suitable for coastal, humid and other harsh outdoor environments.
A: Universal design adapts to most common trapezoidal metal roofs, corrugated metal roofs and partial standing‑seam roof profiles. Not 100% compatible with all special local roof shapes. Please send roof section drawing for compatibility confirmation.
A: No drilling / roof penetration required for most matched metal‑roof profiles. It clamps firmly on roof ribs, greatly lowers roof‑leakage risk.
A: Cooperates with our standard solar mounting rails, works with most standard‑framed PV panels. Special rail or panel parameters need pre‑verification.
A: Place the clamp onto the roof rib, tighten the bolts to grip the roof profile tightly, then fix solar rail on top of the clamp. Follow installation manual for recommended bolt torque, no welding on‑site.
A: Special anti‑slip tooth‑structure inside the clamp. When installed with correct torque according to engineering requirement, it can resist wind‑induced sliding. Spacing and quantity shall follow project load calculation.
