Rol Technology Mobile energy storage systems which is the company mainly focuses on, and include household energy storage systems, industrial and commercial energy storage systems, industrial AGV robot lithium batteries, special vehicle lithium batteries and other special customized lithium batteries or systems.
Operating temperature:‑20℃ ~ +55℃. Container cabinet reaches IP54 protection grade. Liquid‑cooling thermal management keeps stable battery temperature for high‑load continuous operation, adapts to coastal high‑salt‑spray, high‑temperature and cold‑region commercial projects.
Order(MOQ) :
1Payment :
T/TLead Time :
15
Its products are exported to 120 countries and regions around the world and have obtained various global certifications, including UL/IEC/CB/CE/UN38.3/MSDS, etc.
Communication protocol can be customized
Load-bearing brackets are easy to install
Supports up to 15 parallel groups
Compatible with mainstream inverters
Multiple appearance designs
Ultra-thin design
| Product Name: | Y3000 |
| System parameters | |
| Cell type | LFP |
| Battery capacity: | 2.3kWh |
| Rated output power: | 3000W |
| Cycle times (@25℃C): | ≥6000 |
| Input parameters | |
| Mains power charging: | 220-240V~2200W ( MAX ） |
| Fast charging input: | / |
| Vehicle charging input: | 12V=8.5A 100W |
| Photovoltaic charging input: | 12-100V=25A 1200W |
| Output parameters | |
| USB-A: | 5/9/12V=18W MAX(x2)，QC3.0 |
| Type-C: | 100Wx1，PD3.060Wx1，PD3.0 |
| Vehicle charging output: | 13V=10A 130W |
| DC output: | / |
| AC output: | 230V~50Hz，1600W，ACx2 |
| General parameters | |
| APP: | Support |
| Control BOX Dimensions (Width x Depth x Height) : | 400x280x191mm |
| Battery Dimensions (Width x Depth x Height) : | 400x280x305mm |
| Control box Weight: | ≈8.7kg |
| Battery Weight: | ≈20.4kg |
A: It is a container‑or trailer‑based movable lithium‑iron‑phosphate energy‑storage system for commercial and industrial projects. It integrates battery packs, PCS converter, BMS, thermal management, fire‑protection and monitoring system. It can be quickly transported to site, provides large‑scale power storage and output without permanent civil‑construction foundation.
A: Common capacity range: 250kWh‑2MWh; power rating: 100kW‑1MW. Support flexible power‑to‑energy ratio configuration. Larger‑size customized solutions are available for special commercial project demands.
A: LFP lithium battery modules, Battery Management System(BMS), PCS power conversion system, liquid‑cooled / air‑cooled thermal control unit, fire‑suppression system, high‑voltage cabinet, HMI touch screen, container/trailer mobile chassis.
A:‑Grid‑connected mode: peak shaving, demand‑response, grid‑backup ‑Off‑grid mode: standalone power supply for commercial sites ‑PV‑hybrid mode: cooperate with solar PV system to store excess photovoltaic energy ‑Backup power: uninterruptible emergency power for commercial facilities
Support three‑phase AC input & output, also DC port reserved.
